Thermoplastic Sprial 4.5" 20" Casing Centralizer

Brand Name : Puyang Zhongshi Group

Model Number : 4 1/2"~20"

Certification : API,ISO,QHSE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, MoneyGram

Delivery Time : depends on quantity

Packaging Details : Wooden Box

Type : Solid rigid

Material : Thermal Plastic

Size : 4.5"~20" or as request

Vane type : Spiral

Surface process : Coated Powder

Feature : High tensile and corrosion resistance

Contact Now

Thermoplastic sprial Casing Centralizer

Composite Casing Centraliser is the ultimate in down-hole centralisation, offering field proven lower friction coefficients leading to superior drag and rotational torque reduction. High abrasion resistant proprietary engineered polymer ensures maximum stand-off at TD. Robust enough to meet the challenges of today's most demanding wells.

Thermoplastic sprial Casing Centralizer Features

  • Available in sizes 4-1/2" to 20".
  • Reducing the drag force.
  • Reducing flow area.
  • Increase maximum centralization.

Thermoplastic sprial Casing Centralizer Specification

Specification casing size (mm) Hole Size (mm) Inner Diameter (mm) Outer Diameter (mm)
13-3/8″×17-1/2" 340 445 344 439
5"×6 5/8" 127 168 131 162
5-1/2″×8-1/2″ 140 216 142 210
7″×8 1/2″ 178 216 182 210
7"× 9-1/2" 178 241 182 235
9-5/8″×12-1/4″ 244 311 248 305
4-1/2″×6″ 114 152 118 146


Product Tags:

20" Casing Centralizer



4.5" Casing Centralizer



4.5" well centralizers


Cheap Thermoplastic Sprial 4.5" 20" Casing Centralizer for sale

Thermoplastic Sprial 4.5" 20" Casing Centralizer Images
